 Features:
All belt
grinder components manufactured by Shannon Precision
LLC are solid steel or solid billet 6061 aircraft
aluminum, no cast iron or cast aluminum. Optional
pedestal is made from 1" solid steel base with 4"x ¼
wall rectangular tube.
The
same machinists that manufacture this belt grinder
insure top quality in assembly.
All
purchased components are easily replaceable from any
industry standard supplier.
Belt
tension adjustments are made with a hand wheel (no
jam nut locking required)
Belt
tracking is adjusted with a small hand wheel and is
designed in such a way to eliminate any tedious jam
nut locking.
Belt
replacement is a breeze without loosening belt
tension. Simply open safety cover and pull down on
polished steel handle, then slid e
belt off.
When used as a belt grinder, simply loosen the
adjusting bolt, rotate the
main beam to the desired position.
Belt grinder drive is accomplished with a direct
motor coupling, no V-belts to wear out or replace.
Also, due to the direct coupling, vibration is kept
to a minimum.
Belt
grinder design and solid construction diminish
harmful sound levels.
With
optional pedestal, a non-rusting replaceable
1-gallon plastic water container and holder are
included.
Sixty
inch belt length allows longer lasting belt
performance with minimal added belt costs.
Main
beam is adjustable to allow belt position to be
vertical, horizontal or any angle in between.
Two
separate part rest platens are adjustable from zero
to 45 degrees. The main part rest platen is 1" solid
steel to minimize part chatter.
With
an
eight inch diameter serrated rubber contact
wheel, the operator
is able to perform tasks such as sanding, contour
grinding, hollow grinding, knife shaping or other
metal shaping tasks. This
feature is also popular in most wood working shops.
Click here for Sales and Spec
Sheet.
Please
try one of our Belt Grinders. You will see first
hand the quality and workmanship that that we put
into every single unit. Shannon Precision LLC is the
best choice for your Belt Grinder needs.
Click here for Belt Grinder
Warranty.
|
Shannon Precision, LLC
Shannon
Precision LLC has been in business since 1984. Like
our company; The Shannon Precision belt grinder is
built to last. We have designed and manufactured
this belt grinder to address common shortcomings.
Great attention has been given to problem areas such
as vibration, noise, tracking adjustment and
reliability. These problems were successfully
addressed and are proven reliable. Due to these
designs you will experience years of trouble free
heavy duty use from our belt grinder. Whether heavy
duty metal working or for wood working, your
satisfaction is guaranteed!
